Introduction to Project Management |
Example 1.9: Subcontracting Decisions
Making decisions about subcontracting forms an important part of
several medium-to-large scale projects. For example, in the
pharmaceutical industry, the analysis of clinical trials may
be a part of the drug development project that could either be
accomplished by the company's statistical group or be
subcontracted to a statistical consulting firm. The decision may
hinge upon how busy the local statistical group is with other
projects that may delay the results of the analysis for the
drug in question. Further, there may be more than one firm that is
a likely candidate for performing the analysis. As a prerequisite
for deciding whether to assign the analysis subproject to an
external firm, you need to obtain a bid in the form of
estimates of the cost and project duration from the
competing firms as well as a corresponding estimate from
the in-house team.
The cost corresponding to each possible subcontracting firm
may be a combination of the actual costs (consulting fees and so on)
and the tardiness of the project (tardiness being measured as
the time difference between when the results are expected to be available
and the target date for the availability of the results). The
information required could be provided in terms of Gantt charts
and cost analysis charts. Using this information, the project manager
for the drug development project can use the principles of
decision analysis to determine whether to do the analysis
in-house or assign it to an outside consulting firm and
to pick the firm to which the subcontract is to be assigned.
Some of these ideas are illustrated in the following example.
Output 1.9.1: Input Data Sets for Decision Problem
Subcontracting Decision |
The Stage Data Set |
Obs |
_STNAME_ |
_STTYPE_ |
_OUTCOM_ |
_REWARD_ |
_SUCCES_ |
1 |
Assignment |
D |
In_House |
. |
Complete |
2 |
|
|
Consult1 |
-20,000 |
Act_Finish |
3 |
|
|
Consult2 |
-17,500 |
Act_Finish |
4 |
Complete |
C |
On_Time |
. |
Cost |
5 |
|
|
Delay |
-10,000 |
Cost |
6 |
Act_Finish |
C |
Early |
. |
|
7 |
|
|
Late |
. |
|
8 |
|
|
Delay2 |
-1,000 |
|
9 |
Cost |
C |
High |
. |
|
10 |
|
|
Low |
. |
|
Subcontracting Decision |
The Probability Data Set |
Obs |
_GIVEN_ |
_EVENT_ |
_PROB_ |
1 |
|
High |
0.50 |
2 |
|
Low |
0.50 |
3 |
|
On_Time |
0.60 |
4 |
|
Delay |
0.40 |
5 |
Consult1 |
Early |
0.60 |
6 |
Consult1 |
Late |
0.35 |
7 |
Consult1 |
Delay2 |
0.05 |
8 |
Consult2 |
Early |
0.50 |
9 |
Consult2 |
Late |
0.40 |
10 |
Consult2 |
Delay2 |
0.10 |
Subcontracting Decision |
The Payoffs Data Set |
Obs |
_STATE1 |
_STATE2 |
_VALUE_ |
1 |
On_Time |
High |
-12,000 |
2 |
On_Time |
Low |
-9,500 |
3 |
Delay |
High |
-15,000 |
4 |
Delay |
Low |
-11,500 |
5 |
Early |
|
3,500 |
6 |
Late |
|
1,500 |
7 |
Delay2 |
|
0 |
|
The stages of the decision problem are
identified by the STAGEIN= data set, stage, displayed in Output 1.9.1.
As a first step, the drug company needs to decide whether to perform
the analysis in-house or to assign it to one of two consulting firms.
If the in-house team is chosen, the resulting stage is a chance node,
called `Complete',
with two possible outcomes: `On-Time' or `Delay'; if there is
a delay, the resulting cost to the drug company is $10,000.
For each of these two outcomes, there is a second chance
event corresponding to the cost of the analysis.
For each of the two consulting firms,
the outcome can be one of three possibilities: `Early',
`Late', or `Delay2'; if there is a delay, the drug
company imposes a delay penalty of $9,000 on the firm, resulting
in a net reward of -$1,000 (cost of $10,000 minus the penalty of
$9,000).
The PROBIN= data set, prob, identifies the various probabilities
associated with the different possible outcomes at each of the
chance events. The prob data set is also displayed in Output 1.9.1.
The rewards (or payoffs) associated with each of the end stages
are listed in the PAYOFFS= data set, payoff (also listed in
Output 1.9.1). For example, for the in-house team, the high (low)
cost associated with completing the analysis on time is $12,000
($9,500), and so on.
The following program invokes PROC DTREE to solve the decision
problem. The complete decision tree, displayed in Output 1.9.2,
represents the various stages and outcomes of the problem and
identifies the optimal decision. In this example, the drug
company should award the consulting contract to the second
consulting firm as indicated by the red line for the
corresponding branch of the tree.
See Chapter 3, "The DTREE Procedure," for details about the DTREE
procedure.
title f=swiss "Subcontracting Decision";
goptions ftext=swissbu;
symbol1 f=marker v=P c=blue;
symbol2 f=marker v=U c=green;
symbol3 f=marker v=A c=red;
/* PROC DTREE statements */
proc dtree stagein=stage
probin=prob
payoffs=payoff
nowarning
;
evaluate;
treeplot / graphics
compress ybetween=1 cell
lwidth=1 lwidthb=2 hsymbol=2
symbolc=1 symbold=2 symbole=3
;
quit;
Output 1.9.2: Decision Analysis
