Background

It is well known from the literature on nonparametric statistics that variances and, hence, covariances can be computed from pairwise differences instead of deviations from means. (For example, Puri and Sen (1971, pp. 51 -52) show that the variance is a U statistic of degree 2.) Let X = (x_ij) be the data matrix with n observations (rows) and v variables (columns), and let ${\bar{x}_j}$ be the mean of the jth variable. The sample covariance matrix S = (s_jk) is usually defined as

$s_{jk} = \frac{1}{n-1} \sum_{i=1}^n (x_{ij} - {\bar{x}}_j) (x_{ik} - {\bar{x}}_k)$

The matrix S can also be computed as

$s_{jk} = \frac{1}{n(n-1)} \sum_{i=2}^n \sum_{h=1}^{i-1} (x_{ij} - x_{hj}) (x_{ik} - x_{hk})$

Let W = (w_jk) be the pooled within-cluster covariance matrix, q be the number of clusters, n_c be the number of observations in the cth cluster, and

$d^''_{ic} = \{ l} 1 & & {if observation i\space is in cluster c} \0 & & {otherwise} \.$

The matrix W is normally defined as

$w_{jk} = \frac{1}{n-q} \sum_{c=1}^q \sum_{i=1}^n d^''_{ic} (x_{ij} - \bar{x}_{cj}) (x_{ik} - \bar{x}_{ck})$

where $\bar{x}_{cj}$ is the mean of the jth variable in cluster c. Let

$d^'_{ih} = \{ l} \frac{1}{n_c} & & {if observations i\space and h\space are in cluster c} \0 & & {otherwise} \.$

The matrix W can also be computed as

$w_{jk} = \frac{1}{n-q} \sum_{i=2}^n \sum_{h=1}^{i-1} d^'_{ih} (x_{ij} - x_{hj}) (x_{ik} - x_{hk})$

If the clusters are not known, d'_ih cannot be determined. However, an approximation to W can be obtained by using instead

$d^'_{ih} = \{ l} 1 & & {if } \sum_{j=1}^v \sum_{k=1}^v m_{jk} (x_{ij} - x_{hj})(x_{ik} - x_{hk}) \leq u^2 \0 & & {otherwise} \.$

where u is an appropriately chosen value and M = (m_jk) is an appropriate metric. Let A = (a_jk) be defined as

$a_{jk} = \frac{ \sum_{i=2}^n \sum_{h=1}^{i-1} d_{ih} (x_{ij} - x_{hj})(x_{ik} - x_{hk}) } { 2 \sum_{i=2}^n \sum_{h=1}^{i-1} d_{ih} }$

If all of the following conditions hold, A equals W:

all within-cluster distances in the metric M are less than or equal to u
all between-cluster distances in the metric M are greater than u
all clusters have the same number of members n_c

If the clusters are of unequal size, A gives more weight to large clusters than W does, but this discrepancy should be of little importance if the population within-cluster covariance matrices are equal. There may be large differences between A and W if the cutoff u does not discriminate between pairs in the same cluster and pairs in different clusters. Lack of discrimination may occur for one of the following reasons:

The clusters are not well separated.
The metric M or the cutoff u is not chosen appropriately.

In the former case, little can be done to remedy the problem. The remaining question concerns how to choose M and u. Consider M first. The best choice for M is W^-1, but W is not known. The solution is to use an iterative algorithm:

Obtain an initial estimate of A, such as the identity or the total-sample covariance matrix. (See the INITIAL= option in the PROC ACECLUS statement for more information.)
Let M equal A^-1.
Recompute A using the preceding formula.
Repeat steps 2 and 3 until the estimate stabilizes.

Convergence is assessed by comparing values of A on successive iterations. Let A_i be the value of A on the ith iteration and A₀ be the initial estimate of A. Let Z be a user-specified v ×v matrix. (See the METRIC= option in the PROC ACECLUS statement for more information.) The convergence measure is

$e_i = \frac{1}v \parallel Z^'(A_i - A_{i-1})Z \parallel$

where $\parallel ... \parallel$ indicates the Euclidean norm, that is, the square root of the sum of the squares of the elements of the matrix. In PROC ACECLUS, Z can be the identity or an inverse factor of S or diag(S). Iteration stops when e_i falls below a user-specified value. (See the CONVERGE= option or the MAXITER= option in the PROC ACECLUS statement for more information.)

The remaining question of how to choose u has no simple answer. In practice, you must try several different values. PROC ACECLUS provides four different ways of specifying u:

You can specify a constant value for u. This method is useful if the initial estimate of A is quite good. (See the ABSOLUTE option and the THRESHOLD= option in the PROC ACECLUS statement for more information.)
You can specify a threshold value t>0 that is multiplied by the root mean square distance between observations in the current metric on each iteration to give u. Thus, the value of u changes from iteration to iteration. This method is appropriate if the initial estimate of A is poor. (See the THRESHOLD= option in the PROC ACECLUS statement for more information)
You can specify a value p, 0<p<1, to be transformed into a distance u such that approximately a proportion p of the pairwise Mahalanobis distances between observations in a random sample from a multivariate normal distribution will be less than u in repeated sampling. The transformation can be computed only if the number of observations exceeds the number of variables, preferably by at least 10 percent. This method also requires a good initial estimate of A. (See the PROPORTION= option and the ABSOLUTE option in the PROC ACECLUS statement for more information.)
You can specify a value p, 0<p<1, to be transformed into a value t that is then multiplied by $1/\sqrt{2v}$ times the root mean square distance between observations in the current metric on each iteration to yield u. The value of u changes from iteration to iteration. This method can be used with a poor initial estimate of A. (See the PROPORTION= option in the PROC ACECLUS statement for more information.)

In most cases, the analysis should begin with the last method using values of p between 0.5 and 0.01 and using the full covariance matrix as the initial estimate of A.

Proportions p are transformed to distances t using the formula

t² = 2v{ [ F^-1_v,n-v (p) ]^{[(n-v)/(n-1)]} }

where F^-1_v,n-v is the quantile (inverse cumulative distribution) function of an F random variable with v and n-v degrees of freedom. The squared Mahalanobis distance between a single pair of observations sampled from a multivariate normal distribution is distributed as 2v times an F random variable with v and n-v degrees of freedom. The distances between two pairs of observations are correlated if the pairs have an observation in common. The quantile function is raised to the power given in the preceding formula to compensate approximately for the correlations among distances between pairs of observations that share a member. Monte Carlo studies indicate that the approximation is acceptable if the number of observations exceeds the number of variables by at least 10 percent.

If A becomes singular, step 2 in the iterative algorithm cannot be performed because A cannot be inverted. In this case, let Z be the matrix as defined in discussing the convergence measure, and let ${Z^'AZ}={R^' \Lambda R}$ where R'R = RR' = I and ${\Lambda}=(\lambda_{jk})$ is diagonal. Let ${\Lambda^*}=(\lambda_{jk}^*)$ be a diagonal matrix where $\lambda_{jj}^*=\max(\lambda_{jj}, g {trace}({\Lambda}))$ ,and 0<g<1 is a user-specified singularity criterion (see the SINGULAR= option in the PROC ACECLUS statement for more information). Then M is computed as ${ZR^'}({\Lambda^*})^{-1}{RZ^'}$ .

The ACECLUS procedure differs from the method used by Art, Gnanadesikan, and Kettenring (1982) in several respects.

The Art, Gnanadesikan, and Kettenring method uses the identity matrix as the initial estimate, whereas the ACECLUS procedure enables you to specify any symmetric matrix as the initial estimate and defaults to the total-sample covariance matrix. The default initial estimate in PROC ACECLUS is chosen to yield invariance under nonsingular linear transformations of the data but may sometimes obscure clusters that become apparent if the identity matrix is used.
The Art, Gnanadesikan, and Kettenring method carries out all computations with SSCP matrices, whereas the ACECLUS procedure uses estimated covariance matrices because covariances are easier to interpret than crossproducts.
The Art, Gnanadesikan, and Kettenring method uses the m pairs with the smallest distances to form the new estimate at each iteration, where m is specified by the user, whereas the ACECLUS procedure uses all pairs closer than a given cutoff value. Kettenring (1984) says that the m-closest-pairs method seems to give the user more direct control. PROC ACECLUS uses a distance cutoff because it yields a slight decrease in computer time and because in some cases, such as widely separated spherical clusters, the results are less sensitive to the choice of distance cutoff than to the choice of m. Much research remains to be done on this issue.
The Art, Gnanadesikan, and Kettenring method uses a different convergence measure. Let A_i be computed on each iteration using the m-closest-pairs method, and let B_i = A^-1_i-1A_i - I where I is the identity matrix. The convergence measure is equivalent to trace(B_i²).

Analyses of Fisher's (1936) iris data, consisting of measurements of petal and sepal length and width for fifty specimens from each of three iris species, are summarized in Table 16.1. The number of misclassified observations out of 150 is given for four clustering methods:

k-means as implemented in PROC FASTCLUS with MAXC=3, MAXITER=99, and CONV=0
Ward's minimum variance method as implemented in PROC CLUSTER
average linkage on Euclidean distances as implemented in PROC CLUSTER
the centroid method as implemented in PROC CLUSTER

Each hierarchical analysis is followed by the TREE procedure with NCL=3 to determine cluster assignments at the three-cluster level. Clusters with twenty or fewer observations are discarded by using the DOCK=20 option. The observations in a discarded cluster are considered unclassified.

Each method is applied to

the raw data
the data standardized to unit variance by the STANDARD procedure
two standardized principal components accounting for 95 percent of the standardized variance and having an identity total-sample covariance matrix, computed by the PRINCOMP procedure with the STD option
four standardized principal components having an identity total-sample covariance matrix, computed by PROC PRINCOMP with the STD option
the data transformed by PROC ACECLUS using seven different settings of the PROPORTION= (P=) option
four canonical variables having an identity pooled within-species covariance matrix, computed using the CANDISC procedure

Theoretically, the best results should be obtained by using the canonical variables from PROC CANDISC. PROC ACECLUS yields results comparable to PROC CANDISC for values of the PROPORTION= option ranging from 0.005 to 0.02. At PROPORTION=0.04, average linkage and the centroid method show some deterioration, but k-means and Ward's method continue to produce excellent classifications. At larger values of the PROPORTION= option, all methods perform poorly, although no worse than with four standardized principal components.

Table 16.1: Number of Misclassified and Unclassified Observations Using Fisher's (1936) Iris Data

	Clustering Method
			Average
Data	k-means	Ward's	Linkage	Centroid

raw data	16^*	16^*	25+12^**	14^*

standardized data	25	26	33+4	33+4

two standardized
principal components	29	31	30+9	27+32

four standardized
principal components	39	27	32+7	45+11

transformed
by ACECLUS P=0.32	39	10+9	7+25

transformed
by ACECLUS P=0.16	39	18+9	7+19	7+26

transformed
by ACECLUS P=0.08	19	9	3+13	5+16

transformed
by ACECLUS P=0.04	4	5	1+19	3+12

transformed
by ACECLUS P=0.02	4	3	3	3

transformed
by ACECLUS P=0.01	4	4	3	4

transformed
by ACECLUS P=0.005	4	4	4	4

canonical variables	3	5	4	4+1
^* A single number represents misclassified observations with no unclassified observations.
^** Where two numbers are separated by a plus sign, the first is the number of misclassified
observations; the second is the number of unclassified observations.

This example demonstrates the following:

PROC ACECLUS can produce results as good as those from the optimal transformation.
PROC ACECLUS can be useful even when the within-cluster covariance matrices are moderately heterogeneous.
The choice of the distance cutoff as specified by the PROPORTION= or the THRESHOLD= option is important, and several values should be tried.
Commonly used transformations such as standardization and principal components can produce poor classifications.

Although experience with the Art, Gnanadesikan, and Kettenring and PROC ACECLUS methods is limited, the results so far suggest that these methods help considerably more often than they hinder the subsequent cluster analysis, especially with normal-mixture techniques such as k-means and Ward's minimum variance method.
