Tracks 1 &
2
|
Source: Male phoneme, with 1/16 attack & decay (sample repeated) Processing: Start with 2 or 3 voices, offset = 1000
samples, offset range = 100 samples, grain duration = 50 ms, grain env
= 1/16, delay = 500 ms, delay range = 5 ms, ramp = 250 ms. Increment
no. of voices back to 15 bringing in unsynchronized phonemes, then at
approx 24", bring in 15 voices transposed 1 oct. down, then reduce to
half transposed. Around 32" start ramp as below, ending around 3' with
a fade at max. density |
|
Tracks 3 &
4
|
Source: Male phoneme, with 1/16 attack & decay (sample repeated) Processing: Start with 2 or 3 voices, offset = 1000 samples, offset range = 100 samples, grain duration = 50 ms, grain env = 1/16, delay = 500 ms, delay range = 5 ms, ramp = 250 ms. Increment no. of voices back to 18 bringing in unsynchronized phonemes, then at approx 32", bring in all voices transposed 1 oct. up, then reduce to half transposed, and start ramp as below, ending around 3' with a fade at max. density |
|
Tracks 5 &
6
|
Source: Female phoneme, with 1/16 attack & decay (sample repeated) Processing: Start with 2 or 3 voices, offset = 1000 samples, offset range = 100 samples, grain duration = 50 ms, grain env = 1/16, delay = 500 ms, delay range = 5 ms, ramp = 250 ms. Increment no. of voices back to 15 bringing in unsynchronized phonemes, then at approx 24", bring in 15 voices transposed 1 oct. down, then reduce to half transposed. Around 32" start ramp as below, ending around 3' with a fade at max. density |
|
Tracks 7 &
8
|
Source: Female phoneme, with 1/16 attack & decay (sample repeated) Processing: Start with 2 or 3 voices, offset = 1000 samples, offset range = 100 samples, grain duration = 50 ms, grain env = 1/16, delay = 500 ms, delay range = 5 ms, ramp = 250 ms. Increment no. of voices back to 18 bringing in unsynchronized phonemes, then at approx 32", bring in all voices transposed 1 oct. up, then reduce to half transposed, and start ramp as below, ending around 3' with a fade at max. density |
|
Mask Track
|
Starts around 0:52, played at
twice
tape speed, cycles 6 times with FM grains (realized with GRMSKX
program) with c:m ratios 1:2, 1:1, 2:1, 3:1, 4:1, 5:1 for each 20"
cycle; lasts about 2' and fades; see mask details below |
| Time | 0:00 .....................
0:30 .................. 1:00 .......................... 1:30
.................. 2:00 .................. 2:30
........................ 3:00 |
| Graphics click to enlarge |
                                   |
Mask: Frequency mask: 7600/8400 Hz -> 2000/8000 Hz in 15", holds for 10", then back to 7600/8400 Hz in 15"; Duration mask: 68/72 ms -> 18/22 ms in 15", 20/70 ms for 10", then 18/22 -> 68/72 ms in 15"; Delay ramp from 0 -> 25 ms in 15", then 50 -> 0 -> 50 ms in 10"; then 25 -> 0 ms in 15"; Modulation Index mask: 0/0 -> 0/10 in 15", hold for 10", then 0/10 -> 0/0 in 15". Total duration 40". Each mask segment is translated by the program into a ramp on the average and range, similar to the ramp files, since they are functionally equivalent.
