Time Series Analysis and Control Examples

Example 10.2: Kalman Filtering: Likelihood Function Evaluation

In this example, the log likelihood function of the SSM is computed using prediction error decomposition. The annual real GNP series, yt, can be decomposed as
y_t = \mu_t + \epsilon_t
where \mu_t is a trend component and \epsilon_t is a white noise error with \epsilon_t \sim (0, \sigma^2_\epsilon).Refer to Nelson and Plosser (1982) for more details on these data. The trend component is assumed to be generated from the following stochastic equations:
\mu_t & = & \mu_{t-1} + \beta_{t-1} + \eta_{1t} \\beta_t & = & \beta_{t-1} + \eta_{2t}
where \eta_{1t} and \eta_{2t} are independent white noise disturbances with \eta_{1t} \sim (0, \sigma^2_{\eta_1}) and \eta_{2t} \sim (0, \sigma^2_{\eta_2}).

It is straightforward to construct the SSM of the real GNP series.

y_t & = & H{z}_t + \epsilon_t \z_t & = & F{z}_{t-1} + \eta_t
where
H& = & (1, 0) \
F& = & [ 1 & 1 \
 0 & 1
 ] \
z_t & = & (\mu_t, \beta_t)^' \\...
 ...ma^2_\epsilon & 0 & 0 \ 0 & \sigma^2_{\eta 1} & 0 \ 0 & 0 & \sigma^2_{\eta 2}
 ]
When the observation noise \epsilon_t is normally distributed, the average log likelihood function of the SSM is
\ell & = & \frac{1}T \sum_{t=1}^T \ell_t \
\ell_t & = & -\frac{N_y}2\log(2\pi) ...
 ...ac{1}2\log(|{C}_t|)
 - \frac{1}2 \hat{\epsilon}^'_t
 C^{-1}_t \hat{\epsilon}_t
where Ct is the mean square error matrix of the prediction error \hat{\epsilon}_t, such that C_t = H{P}_{t| t-1} H^' + R_t.

The LIK module computes the average log likelihood function. First, the average log likelihood function is computed using the default initial values: Z0=0 and VZ0=106I. The second call of module LIK produces the average log likelihood function with the given initial conditions: Z0=0 and VZ0=10-3I. You can notice a sizable difference between the uncertain initial condition (VZ0=106I) and the almost deterministic initial condition (VZ0=10-3I) in Output 10.2.1.

Finally, the first 15 observations of one-step predictions, filtered values, and real GNP series are produced under the moderate initial condition (VZ0=10I). The data are the annual real GNP for the years 1909 to 1969.

   title 'Likelihood Evaluation of SSM';
   title2 'DATA: Annual Real GNP 1909-1969';
   data gnp;
      input y @@;
   datalines;
   116.8 120.1 123.2 130.2 131.4 125.6 124.5 134.3
   135.2 151.8 146.4 139.0 127.8 147.0 165.9 165.5
   179.4 190.0 189.8 190.9 203.6 183.5 169.3 144.2
   141.5 154.3 169.5 193.0 203.2 192.9 209.4 227.2
   263.7 297.8 337.1 361.3 355.2 312.6 309.9 323.7
   324.1 355.3 383.4 395.1 412.8 406.0 438.0 446.1
   452.5 447.3 475.9 487.7 497.2 529.8 551.0 581.1
   617.8 658.1 675.2 706.6 724.7
   ;

   proc iml;
   start lik(y,a,b,f,h,var,z0,vz0);
       nz = nrow(f);
       n = nrow(y);
       k = ncol(y);
       const = k*log(8*atan(1));
       if ( sum(z0 = .) | sum(vz0 = .) ) then
          call kalcvf(pred,vpred,filt,vfilt,y,0,a,f,b,h,var);
       else
          call kalcvf(pred,vpred,filt,vfilt,y,0,a,f,b,h,var,z0,vz0);
       et = y - pred*h`;
       sum1 = 0;
       sum2 = 0;
       do i = 1 to n;
          vpred_i = vpred[(i-1)*nz+1:i*nz,];
          et_i = et[i,];
          ft = h*vpred_i*h` + var[nz+1:nz+k,nz+1:nz+k];
          sum1 = sum1 + log(det(ft));
          sum2 = sum2 + et_i*inv(ft)*et_i`;
       end;
       return(-const-.5*(sum1+sum2)/n);
   finish;

   start main;
      use gnp;
      read all var {y};

      f = {1 1, 0 1};
      h = {1 0};
      a = j(nrow(f),1,0);
      b = j(nrow(h),1,0);
      var = diag(j(1,nrow(f)+ncol(y),1e-3));
      /*-- initial values are computed --*/
      z0 = j(1,nrow(f),.);
      vz0 = j(nrow(f),nrow(f),.);
      logl = lik(y,a,b,f,h,var,z0,vz0);
      print 'No initial values are given', logl;
      /*-- initial values are given --*/
      z0 = j(1,nrow(f),0);
      vz0 = 1e-3#i(nrow(f));
      logl = lik(y,a,b,f,h,var,z0,vz0);
      print 'Initial values are given', logl;
      z0 = j(1,nrow(f),0);
      vz0 = 10#i(nrow(f));
      call kalcvf(pred,vpred,filt,vfilt,y,1,a,f,b,h,var,z0,vz0);
      print y pred filt;
   finish;
   run;

Output 10.2.1: Average Log Likelihood of SSM

Likelihood Evaluation of SSM
DATA: Annual Real GNP 1909-1969

LOGL
-26314.66

LOGL
-91884.41


Output 10.2.2 shows the observed data, the predicted state vectors, and the filtered state vectors for the first 16 observations.

Output 10.2.2: Filtering and One-Step Prediction

Y PRED   FILT
116.8 0 0 116.78832 0
120.1 116.78832 0 120.09967 3.3106857
123.2 123.41035 3.3106857 123.22338 3.1938303
130.2 126.41721 3.1938303 129.59203 4.8825531
131.4 134.47459 4.8825531 131.93806 3.5758561
125.6 135.51391 3.5758561 127.36247 -0.610017
124.5 126.75246 -0.610017 124.90123 -1.560708
134.3 123.34052 -1.560708 132.34754 3.0651076
135.2 135.41265 3.0651076 135.23788 2.9753526
151.8 138.21324 2.9753526 149.37947 8.7100967
146.4 158.08957 8.7100967 148.48254 3.7761324
139 152.25867 3.7761324 141.36208 -1.82012
127.8 139.54196 -1.82012 129.89187 -6.776195
147 123.11568 -6.776195 142.74492 3.3049584
165.9 146.04988 3.3049584 162.36363 11.683345
165.5 174.04698 11.683345 167.02267 8.075817
