The NLP Procedure

Optimization Algorithms

There are three groups of optimization techniques available in PROC NLP. A particular optimizer can be selected with the TECH=name option in the PROC NLP statement.

Algorithm TECH=
Linear Complementary ProblemLICOMP
Quadratic Active Set TechniqueQUADAS
Trust-Region MethodTRUREG
Newton-Raphson Method With Line-SearchNEWRAP
Newton-Raphson Method With RidgingNRRIDG
Quasi-Newton Methods (DBFGS, DDFP, BFGS, DFP)QUANEW
Double-Dogleg Method (DBFGS, DDFP)DBLDOG
Conjugate Gradient Methods (PB, FR, PR, CD)CONGRA
Nelder-Mead Simplex MethodNMSIMP
Levenberg-Marquardt MethodLEVMAR
Hybrid Quasi-Newton Methods (DBFGS, DDFP)HYQUAN

Since no single optimization technique is invariably superior to others, PROC NLP provides a variety of optimization techniques that work well in various circumstances. However, it possible to devise problems for which none of the techniques in PROC NLP can find the correct solution. Moreover, nonlinear optimization can be computationally expensive in terms of time and memory, so care must be taken when matching an algorithm to a problem.

All optimization techniques in PROC NLP use O(n2) memory except the conjugate gradient methods, which use only O(n) memory and are designed to optimize problems with many variables. Since the techniques are iterative, they require the repeated computation of

However, since each of the optimizers requires different derivatives and supports different types of constraints, some computational efficiencies can be gained. The following table shows, for each optimization technique, which derivatives are needed (FOD: first-order derivatives; SOD: second-order derivatives) and what kind of constraints (BC: boundary constraints; LIC: linear constraints; NLC: nonlinear constraints) are supported.

Algorithm FOD SOD BC LIC NLC
LICOMP--xx-
QUADAS--xx-
TRUREGxxxx-
NEWRAPxxxx-
NRRIDGxxxx-
QUANEWx-xxx
DBLDOGx-xx-
CONGRAx-xx-
NMSIMP--xxx
LEVMARx-xx-
HYQUANx-xx-

Preparation for Using Optimization Algorithms

It is rare that a problem is submitted to an optimization algorithm "as is." By making a few changes in your problem, you can reduce its complexity, that would increase the chance of convergence and save execution time.

Choosing an Optimization Algorithm

The factors that go into choosing a particular optimizer for a particular problem are complex and may involve trial and error. The following should be taken into account: First, the structure of the problem has to be considered: Is it quadratic? least-squares? Does it have linear or nonlinear constraints? Next, it is important to consider the type of derivatives of the objective function and the constraints that are needed and whether these are analytically tractable or not. This section provides some guidelines for making the right choices.

For many optimization problems, computing the gradient takes more computer time than computing the function value, and computing the Hessian sometimes takes much more computer time and memory than computing the gradient, especially when there are many decision variables. Optimization techniques that do not use the Hessian usually require more iterations than techniques that do use Hessian approximations (such as finite differences or BFGS update) and so are often slower. Techniques that do not use Hessians at all tend to be slow and less reliable.

The derivative compiler is not efficient in the computation second-order derivatives. For large problems, memory and computer time can be saved by programming your own derivatives using the GRADIENT, JACOBIAN, CRPJAC, HESSIAN, and JACNLC statements. If you are not able or willing to specify first- and second-order derivatives of the objective function, you can rely on finite difference gradients and Hessian update formulas. This combination is frequently used and works very well for small and medium size problems. For large size problems, you are advised not to use an optimization technique that requires the computation of second derivatives.

The following provides some guidance for matching an algorithm to a particular problem.

Quadratic Programming Method

The QUADAS and LICOMP algorithms can be used to minimize or maximize a quadratic objective function,
f(x) = {1 \over 2} x^T G x + g^T x + c,
  {with}  G^T = G
with linear or boundary constraints
A x \geq b  { or }  l_j \leq x_j \leq u_j
where x = (x1, ... ,xn)T, g = (g1, ... ,gn)T, G is an n ×n symmetric matrix, A is an m ×n matrix of general linear constraints, and b = (b1, ... ,bm)T. The value of c modifies only the value of the objective function, not its derivatives, and the location of the optimizer x* does not depend on the value of the constant term c. For QUADAS or LICOMP, the objective function must be specified using the MINQUAD or MAX QUAD statement or using an INQUAD= data set. In this case, derivatives do not need to be specified. because the gradient vector
\nabla f(x) = G x + g
and the n ×n Hessian matrix
\nabla^2 f(x) = G
are easily obtained from the data input.

Simple boundary and general linear constraints can be specified using the BOUNDS or LINCON statement or an INQUAD= or INEST= data set.

General Quadratic Programming (QUADAS)

The QUADAS algorithm is an active set method that iteratively updates the QT decomposition of the matrix Ak of active linear constraints and the Cholesky factor of the projected Hessian ZTGZ simultaneously. The update of active boundary and linear constraints is done separately; refer to Gill et al. (1984). Here Q is an nfree ×nfree orthogonal matrix composed of vectors spanning the null space Z of Ak in its first nfree - nalc columns and range space Y in its last nalc columns; T is an nalc ×nalc triangular matrix of special form, tij=0 for i < n-j, where nfree is the number of free parameters (n minus the number of active boundary constraints), and nalc is the number of active linear constraints. The Cholesky factor of the projected Hessian matrix ZTkGZk and the QT decomposition are updated simultaneously when the active set changes.

Linear Complementarity (LICOMP)

The LICOMP technique solves a quadratic problem as a linear complementarity problem. It can be used only if G is positive (negative) semi-definite for minimization (maximization) and if the parameters are restricted to be positive.

This technique finds a point that meets the Karush-Kuhn-Tucker conditions by solving the linear complementary problem

w = M z + q
with constraints
w^T z \geq 0 ,  w \geq 0,  z \geq 0
where
z = [ x \ \lambda \ ]
 M = [ G & -A^T \ A & 0 \ ]
 q = [ g \ -b \ ]
Only the LCEPSILON= option can be used to specify a tolerance used in computations.

General Nonlinear Optimization

Trust-Region Optimization (TRUREG)

The trust-region method uses the gradient g(x(k)) and Hessian matrix G(x(k)) and thus requires that the objective function f(x) have continuous first- and second-order derivatives inside the feasible region.

The trust-region method iteratively optimizes a quadratic approximation to the nonlinear objective function within a hyperelliptic trust region with radius \Delta that constrains the step size corresponding to the quality of the quadratic approximation. The trust-region method is implemented using Dennis, Gay, & Welsch (1981), Gay (1983), and Mor\acute{e} & Sorensen (1983) .

The trust region method performs well for small to medium-sized problems and does not require many function, gradient, and Hessian calls. If the computation of the Hessian matrix is computationally expensive, use the UPDATE= option for update formulas (that gradually build the second-order information in the Hessian). For larger problems, the conjugate gradient algorithm may be more appropriate.

Newton-Raphson Optimization With Line-Search (NEWRAP)

The NEWRAP technique uses the gradient g(x(k)) and Hessian matrix G(x(k)) and thus requires that the objective function have continuous first- and second-order derivatives inside the feasible region. If second-order derivatives are computed efficiently and precisely, the NEWRAP method may perform well for medium-sized to large problems, and it does not need many function, gradient, and Hessian calls.

This algorithm uses a pure Newton step when the Hessian is positive definite and when the Newton step reduces the value of the objective function successfully. Otherwise, a combination of ridging and line-search is done to compute successful steps. If the Hessian is not positive definite, a multiple of the identity matrix is added to the Hessian matrix to make it positive definite (Eskow and Schnabel 1991).

In each iteration, a line-search is done along the search direction to find an approximate optimum of the objective function. The default line-search method uses quadratic interpolation and cubic extrapolation (LIS=2).

Newton-Raphson Ridge Optimization (NRRIDG)

The NRRIDG technique uses the gradient g(x(k)) and Hessian matrix G(x(k)) and thus requires that the objective function have continuous first- and second-order derivatives inside the feasible region.

This algorithm uses a pure Newton step when the Hessian is positive definite and when the Newton step reduces the value of the objective function successfully. If at least one of these two conditions is not satisfied, a multiple of the identity matrix is added to the Hessian matrix. If this algorithm is used for least-squares problems, it performs a ridged Gauss-Newton minimization.

The NRRIDG method performs well for small to medium-sized problems and does not need many function, gradient, and Hessian calls. However, if the computation of the Hessian matrix is computationally expensive, one of the (dual) quasi-Newton or conjugate gradient algorithms may be more efficient.

Since NRRIDG uses an orthogonal decomposition of the approximate Hessian, each iteration of NRRIDG can be slower than that of NEWRAP, that works with Cholesky decomposition. However, usually NRRIDG needs fewer iterations than NEWRAP.

Quasi-Newton Optimization (QUANEW)

The (dual) quasi-Newton method uses the gradient g(x(k)) and does not need to compute second-order derivatives since they are approximated. It works well for medium to moderately large optimization problems where the objective function and the gradient are much faster to compute than the Hessian, but in general it requires more iterations than the techniques TRUREG, NEWRAP, and NRRIDG, which compute second-order derivatives.

The QUANEW algorithm depends on whether or not there are nonlinear constraints.

[cnlpfunorlin]Unconstrained or Linearly Constrained Problems

If there are no nonlinear constraints, QUANEW is either

depending upon the value of the UPDATE= options. For problems with general linear inequality constraints, the dual quasi-Newton methods can be more efficient than the original ones.

Four update formulas can be specified with the UPDATE= option:

DBFGS
performs the dual BFGS (Broyden, Fletcher, Goldfarb, & Shanno) update of the Cholesky factor of the Hessian matrix. This is the default.
DDFP
performs the dual DFP (Davidon, Fletcher, & Powell) update of the Cholesky factor of the Hessian matrix.
BFGS
performs the original BFGS (Broyden, Fletcher, Goldfarb, & Shanno) update of the inverse Hessian matrix.
DFP
performs the original DFP (Davidon, Fletcher, & Powell) update of the inverse Hessian matrix.

In each iteration, a line-search is done along the search direction to find an approximate optimum. The default line-search method uses quadratic interpolation and cubic extrapolation to obtain a step size \alpha satisfying the Goldstein conditions. One of the Goldstein conditions can be violated if the feasible region defines an upper limit of the step size. Violating the left side Goldstein condition can affect the positive definiteness of the quasi-Newton update. In those cases, either the update is skipped or the iterations are restarted with an identity matrix resulting in the steepest descent or ascent search direction. Line-search algorithms other than the default one can be specified with the LIS= option.

[cnlpfconstrained]Nonlinearly Constrained Problems

The algorithm used for nonlinearly constrained quasi-Newton optimization is an efficient modification of Powell's (1978, 1982) Variable Metric Constrained WatchDog (VMCWD) algorithm. A similar but older algorithm (VF02AD) is part of the Harwell library. Both VMCWD and VF02AD use Fletcher's VE02AD algorithm (part of the Harwell library) for positive definite quadratic programming. The PROC NLP QUANEW implementation uses a quadratic programming subroutine that updates and downdates the approximation of the Cholesky factor when the active set changes. The nonlinear QUANEW algorithm is not a feasible point algorithm, and the value of the objective function need not decrease (minimization) or increase (maximization) monotonically. Instead, the algorithm tries to reduce a linear combination of the objective function and constraint violations, called the merit function.

The following are similarities and differences between this algorithm and the VMCWD algorithm:

The nonlinear QUANEW algorithm needs the Jacobian matrix of the first-order derivatives (constraints normals) of the constraints CJ(x).

You can specify two update formulas with the UPDATE=option: This algorithm uses its own line-search technique. All options and parameters (except the INSTEP= option) controlling the line-search in the other algorithms do not apply here. In several applications, large steps in the first iterations were troublesome. You can use the INSTEP= option to impose an upper bound for the step size \alpha during the first five iterations. You may also use the INHESSIAN[=r] option to specify a different starting approximation for the Hessian. Choosing simply the INHESSIAN option will use the Cholesky factor of a (possibly ridged) finite difference approximation of the Hessian to initialize the quasi-Newton update process. The values of the LCSINGULAR=, LCEPSILON=, and LCDEACT= options, which control the processing of linear and boundary constraints, are valid only for the quadratic programming subroutine used in each iteration of the nonlinear constraints QUANEW algorithm.

Double Dogleg Optimization (DBLDOG)



The double dogleg optimization method combines the ideas of quasi-Newton and trust region methods. The double dogleg algorithm computes in each iteration the step s(k) as the linear combination of the steepest descent or ascent search direction s1(k) and a quasi-Newton search direction s2(k),
s^{(k)} = \alpha_1 s_1^{(k)} + \alpha_2 s_2^{(k)}
The step is requested to remain within a prespecified trust region radius, refer to Fletcher (1987, p. 107). Thus, the DBLDOG subroutine uses the dual quasi-Newton update but does not perform a line-search. Two update formulas can be specified with the UPDATE= option:
DBFGS
performs the dual BFGS (Broyden, Fletcher, Goldfarb, & Shanno) update of the Cholesky factor of the Hessian matrix. This is the default.
DDFP
performs the dual DFP (Davidon, Fletcher, & Powell) update of the Cholesky factor of the Hessian matrix.

The double dogleg optimization technique works well for medium to moderately large optimization problems where the objective function and the gradient are much faster to compute than the Hessian. The implementation is based on Dennis & Mei (1979) and Gay (1983) but is extended for dealing with boundary and linear constraints. DBLDOG generally needs more iterations than the techniques TRUREG, NEWRAP, or NRRIDG that need second-order derivatives, but each of the DBLDOG iterations is computationally cheap. Furthermore, DBLDOG needs only gradient calls for the update of the Cholesky factor of an approximate Hessian.

Conjugate Gradient Optimization (CONGRA)



Second-order derivatives are not used by CONGRA. The CONGRA algorithm can be expensive in function and gradient calls but needs only O(n) memory for unconstrained optimization. In general, many iterations are needed to obtain a precise solution, but each of the CONGRA iterations is computationally cheap. Four different update formulas for generating the conjugate directions can be specified using the UPDATE= option:
PB
performs the automatic restart update method of Powell (1977) and Beale (1972). This is the default.
FR
performs the Fletcher-Reeves update (Fletcher 1987).
PR
performs the Polak-Ribiere update (Fletcher 1987).
CD
performs a conjugate-descent update of Fletcher (1987).

The default value is UPDATE=PB, since it behaved best in most test examples. You are advised to avoid the option UPDATE=CD, that behaved worst in most test examples.

The CONGRA subroutine should be used for optimization problems with large n. For the unconstrained or boundary constrained case, CONGRA needs only O(n) bytes of working memory, whereas all other optimization methods require order O(n2) bytes of working memory. During n successive iterations, uninterrupted by restarts or changes in the working set, the conjugate gradient algorithm computes a cycle of n conjugate search directions. In each iteration, a line-search is done along the search direction to find an approximate optimum of the objective function. The default line-search method uses quadratic interpolation and cubic extrapolation to obtain a step size \alpha satisfying the Goldstein conditions. One of the Goldstein conditions can be violated if the feasible region defines an upper limit for the step size. Other line-search algorithms can be specified with the LIS= option.

Nelder-Mead Simplex Optimization (NMSIMP)



The Nelder-Mead simplex method does not use any derivatives and does not assume that the objective function has continuous derivatives. The objective function itself needs to be continuous. This technique requires a large number of function evaluations. It is unlikely to give accurate results for n \gg 40.

Depending on the kind of constraints, one of the following Nelder-Mead simplex algorithms is used: The original Nelder-Mead algorithm cannot be used for general linear or nonlinear constraints but can be faster for the unconstrained or boundary constrained case. The original Nelder-Mead algorithm changes the shape of the simplex adapting the nonlinearities of the objective function which contributes to an increased speed of convergence. The two NMSIMP subroutines use special sets of termination criteria. For more details, refer to the section "Termination Criteria".

[cnlpfcoby]Powell's COBYLA Algorithm (COBYLA)

Powell's COBYLA algorithm is a sequential trust-region algorithm (originally with a monotonically decreasing radius \rho of a spheric trust region) that tries to maintain a regular-shaped simplex over the iterations. A small modification was made to the original algorithm, that permits an increase of the trust-region radius \rho in special situations. A sequence of iterations is performed with a constant trust-region radius \rhountil the computed objective function reduction is much less than the predicted reduction. Then, the trust-region radius \rho is reduced. The trust-region radius is increased only if the computed function reduction is relatively close to the predicted reduction and the simplex is well-shaped. The start radius \rho_{beg} and the final radius \rho_{end}can be specified using \rho_{beg}=INSTEP and \rho_{end}=ABSXTOL. The convergence to small values of \rho_{end} (high precision) may take many calls of the function and constraint modules and may result in numerical problems. There are two main reasons for the slow convergence of the COBYLA algorithm:

Nonlinear Least-Squares Optimization

Levenberg-Marquardt Least-Squares Method (LEVMAR)



The Levenberg-Marquardt method is a modification of the trust-region method for nonlinear least-squares problems and is implemented as in Mor\acute{e} (1978).

This is the recommended algorithm for small- to medium-sized least-squares problems. Large least-squares problems can be transformed into minimization problems, which can be processed with conjugate gradient or (dual) quasi-Newton techniques. In each iteration, LEVMAR solves a quadratically constrained quadratic minimization problem that restricts the step to stay at the surface of or inside an n dimensional elliptical (or spherical) trust region. In each iteration, LEVMAR uses the crossproduct Jacobian matrix JTJ as an approximate Hessian matrix.

Hybrid Quasi-Newton Least-Squares Methods (HYQUAN)



In each iteration of one of the Fletcher and Xu (1987) (refer also to AlBaali and Fletcher 1985, 1986) hybrid quasi-Newton methods, a criterion is used to decide whether a Gauss-Newton or a dual quasi-Newton search direction is appropriate. The VERSION= option can be used to choose one of three criteria (HY1, HY2, HY3) proposed by Fletcher and Xu (1987). The default is VERSION=2; that is, HY2. In each iteration, HYQUAN computes the crossproduct Jacobian (used for the Gauss-Newton step), updates the Cholesky factor of an approximate Hessian (used for the quasi-Newton step), and does a line-search to compute an approximate minimum along the search direction. The default line-search technique used by HYQUAN is especially designed for least-squares problems (refer to Lindstr\ddot{o}m and Wedin 1984 and AlBaali and Fletcher, 1986). Using the LIS= option you can choose a different line-search algorithm than the default one. Two update formulas can be specified with the UPDATE= option:
DBFGS
performs the dual BFGS (Broyden, Fletcher, Goldfarb, and Shanno) update of the Cholesky factor of the Hessian matrix. This is the default.
DDFP
performs the dual DFP (Davidon, Fletcher, and Powell) update of the Cholesky factor of the Hessian matrix.

The HYQUAN subroutine needs about the same amount of working memory as the LEVMAR algorithm. In most applications, LEVMAR seems to be superior to HYQUAN, and using HYQUAN is recommended only when problems are experienced with the performance of LEVMAR.
