Example 24.1: Nonstandard Linear Model

See OPTEX3 in the SAS/QC Sample Library

The following example is based on an example in Mitchell (1974a). An animal scientist wants to compare wildlife densities in four different habitats over a year. However, due to the cost of experimentation, only 12 observations can be made. The following model is postulated for the density y_j(t) in habitat j during month t:

$y_j(t) & = & \mu_j + \beta t + \sum_{i=1}^4 a_i \cos(i\pi t/4) + \sum_{i=1}^3 b_i \sin(i\pi t/4).$

This model includes the habitat as a classification variable, the effect of time with an overall linear drift term $\beta t$ , and cyclic behavior in the form of a Fourier series. There is no intercept term in the model.

The OPTEX procedure is used since there are no standard designs that cover this situation. The candidate set is the full factorial arrangement of four habitats by 12 months, which can be generated with a DATA step, as follows:

   data a;
      drop theta pi;
      array c{4} c1-c4;
      array s{3} s1-s3;
      pi = arcos(-1);
      do habitat=1 to 4;
         do month=1 to 12;
            theta = pi * month / 4;
            do i=1 to 4; c{i} = cos(i*theta); end;
            do i=1 to 3; s{i} = sin(i*theta); end;
            output;
         end;
      end;
   run;

Data set A contains the 48 candidate points and includes the cosine variables (C1, C2, C3, and C4) and sine variables (S1, S2, S3, S4). The following statements produce Output 24.1.1:

   proc optex seed=193030034 data=a;
      class    habitat;
      model    habitat month c1-c4 s1-s3 / noint;
      generate n=12;
   run;

Output 24.1.1: Sampling Wildlife Habitats Over Time

The OPTEX Procedure

Design Number	D-Efficiency	A-Efficiency	G-Efficiency	Average Prediction Standard Error
1	31.6103	19.7379	57.7350	1.3229
2	31.6103	19.7379	57.7350	1.3229
3	31.6103	19.3793	57.7350	1.3229
4	31.6103	19.2916	57.7350	1.3229
5	31.6103	19.2626	57.7350	1.3229
6	31.6103	19.0335	57.7350	1.3229
7	30.1304	14.8837	44.7214	1.4907
8	30.1304	14.2433	44.7214	1.5092
9	30.1304	13.1687	44.7214	1.5456
10	28.1616	9.8842	40.8248	1.7559

The best determinant (D-efficiency) was found in 6 out of the 10 tries. Thus, you can be confident that this is the best achievable determinant. Only the A-efficiency distinguishes among the designs listed in Output 24.1.1. The best design has an A-efficiency of 19.74%, whereas another design has the same D-efficiency but a slightly smaller A-efficiency of 19.03%, or about 96% relative A-efficiency. To explore the differences, you can save the designs in data sets and print them. Since the OPTEX procedure is interactive, you need to submit only the following statements (immediately after the preceding statements) to produce Output 24.1.2 and Output 24.1.3:

      output out=d1 number=1;
   run;
      output out=d6 number=6;
   run;

   proc sort data=d1;
      by  month habitat;
   proc print data=d1;
      var month habitat;
   run;

   proc sort data=d6;
      by  month habitat;
   proc print data=d6;
      var month habitat;
   run;

Output 24.1.2: The Best Design

Obs	month	habitat
1	1	3
2	2	2
3	3	4
4	4	1
5	5	4
6	6	1
7	7	2
8	8	3
9	9	4
10	10	1
11	11	2
12	12	3

Output 24.1.3: Design with Lower A-Efficiency

Obs	month	habitat
1	1	4
2	2	2
3	3	3
4	4	1
5	5	1
6	6	4
7	7	4
8	8	1
9	9	2
10	10	1
11	11	4
12	12	3

Note the structure of the best design in Output 24.1.2. One habitat is sampled in each month, each habitat is sampled three times, and the habitats are sampled in consecutive complete blocks. Even though the design in Output 24.1.3 is as D-efficient as the best, it has almost none of this structure; one habitat is sampled each month, but habitats are not sampled an equal number of times. This demonstrates the importance of choosing a final design on the basis of more than one criterion.

You can try searching for the A-optimal design directly. This takes more time but (with only 48 candidate points) is not too large a problem. The following statements produce Output 24.1.4:

   proc optex seed=193030034 data=a;
      class    habitat;
      model    habitat month c1-c4 s1-s3 / noint;
      generate n=12 criterion=A;
   run;

Output 24.1.4: Searching Directly for an A-efficient Design

The OPTEX Procedure

Design Number	D-Efficiency	A-Efficiency	G-Efficiency	Average Prediction Standard Error
1	31.6103	19.7379	57.7350	1.3229
2	30.1304	17.8273	52.2233	1.3894
3	30.1304	17.7943	52.2233	1.3944
4	30.1304	17.6471	52.2233	1.4093
5	28.1616	15.7055	44.7214	1.4860
6	28.1616	14.5289	44.7214	1.5343
7	28.1616	13.8603	39.2232	1.5811
8	25.0891	11.6152	37.7964	1.8143
9	25.0891	10.7563	37.7964	1.8143
10	25.0891	10.5437	33.3333	1.8930

The best design found is no more A-efficient than the one found previously.
