## Section46.2Combinatorial Geometry

Let us $3$–colour the points of the plane. Prove that there will be two points at distance $1$ with the same colour.

Solution

We $3$–colour the points of the plane and throw the Moser spindle in the plane. There must be two points at distance $1$ with the same colour.

We $2$–colour the points of the plane. Suppose that there are three points of the same colour forming a regular (equilateral) triangle with side 1 (a monochromatic regular triangle with side 1, for short). Then for each $a,b\gt 0$ such that $|a-b| \lt 1 \lt a+b\text{,}$ we have a monochromatic triangle with sides $1, a, b\text{.}$

Solution

Suppose that $\triangle ABC$ is red regular triangle with side 1.
Consider the set of points $\{D,E,F,G,H\}$ so that $\triangle ACD\text{,}$ $\triangle ABF\text{,}$ $\triangle BDF\text{,}$ $\triangle BCE\text{,}$ $\triangle BGH\text{,}$ and $\triangle DFH$ be six mutually congruent triangles with sides $1, a, b\text{.}$

If any of the vertices $D,F$ or $E$ is red the then one of $\triangle ACD\text{,}$ $\triangle ABF\text{,}$ or $\triangle BCE$ is a red triangle with sides $1, a, b\text{.}$

Suppose that $D,F$ and $E$ are blue.

If both $G$ and $H$ are red then $\triangle BHG$ is a red triangle with sides $1, a, b\text{.}$

If one of $G$ or $H$ is blue then there is a blue triangle with sides $1, a, b\text{.}$

1. Show that if we $2$–colour the points of the plane, then we do not necessarily have a monochromatic regular triangle with side 1.

2. Prove that in any $2$–colouring of the points of the plane, we always have a monochromatic triangle with sides $\sqrt{2}\text{,}$ $\sqrt{6}\text{,}$ and $\pi\text{.}$

Solution
1. We cover the plane with stripes of width $\frac{\sqrt{3}}{2}\text{,}$ that alternate in the colours, red and blue. Each strip includes its lower edge. It is not difficult to see that any equilateral triangle with the side 1 thrown in such a plane will have exactly two vertices of the same colour.

2. We consider $1\text{, }\sqrt{3}\text{, }\frac{\pi}{\sqrt{2}}$ since we can obtain the case in the statement of the problem by multiplying each of them by $\frac{1}{\sqrt{2}}\text{.}$
Our strategy is to prove that any $2$–colouring of the points of the plane, yields a monochromatic triangle with sides $1$ or $\sqrt{3}\text{.}$ Since $\frac{\pi}{\sqrt{2}}-\sqrt{3}\lt 1\lt\frac{\pi}{\sqrt{2}}+\sqrt{3}$ and $\frac{\pi}{\sqrt{2}}-1\lt \sqrt{3}\lt\frac{\pi}{\sqrt{2}}+1\text{,}$ by Problem 46.2.2, there must exist a monochromatic triangle with sides $1\text{, }\sqrt{3}\text{, }\frac{\pi}{\sqrt{2}}\text{.}$
Suppose that a $2$– colouring uses both colours.

Observe that if $A$ and $B$ are of different colours then, since we can connect them by a polygonal line with sides $2\text{,}$ there are two points with different colours and at the distance $2\text{.}$

We suppose that $A$ is red and that $B$ is coloured blue and that the distance between them is $2\text{.}$

Let $C$ the midpoint of the line segment $\overline{AB}\text{.}$ We consider two more points, $D$ and $E\text{,}$ so that $|\overline{AD}|=\overline{AE}=1\text{,}$ $|\overline{BD}|=\overline{BE}=\sqrt{3}\text{,}$ and $|\overline{CD}|=\overline{CE}=1\text{.}$ We obtain the graph depicted in the figure. .

Suppose that the point $C$ is red. If one of the points $D$ or $E$ is red, then there is a red-monochromatic equilateral triangle of side $1\text{.}$ If both $D$ and $E$ are blue then $\triangle BDE$ is a monochromatic equilateral triangle of side $\sqrt{3}\text{.}$

Does there exist a natural number $n=n_{0}(k,R)$ such that, if we $k$–colour the points of the $n$–dimensional Euclidean space, one of the colours will contain a configuration congruent to $R\text{,}$ where (a) $R$ is a rectangle; and (b) $R$ is a non–rectangular parallelogram.

Solution

(a) Let $a\gt 0$ and $b\gt 0$ be the lengths of edges of the rectangle $R$ and let $N=k^{k+1}\text{.}$

Let $v_0,\ldots,v_N$ be the vertices of a regular simplex in the $N$–dimensional space with side length $a$ and let $w_0,\ldots,w_k$ be the vertices of a regular simplex in the $k$–dimensional space with side length $b\text{.}$

Observe that the set

\begin{equation*} P=\{v_0,\ldots,v_N\}\times \{w_0,\ldots,w_k\}=\{(v_i,w_j): 0\leq i\leq N\text{ and }0\leq j\leq k\} \end{equation*}

is a set of points in the $(N+k)$–dimensional space. Also observe that for each fixed $i\text{,}$ the set $(k+1)$–element set $P_i=\{(v_i,w_j):0\leq j\leq k\}$ can be coloured in $k^{k+1}=N$ ways.

Let $c$ be a $k$–colouring of the $(N+k)$–dimensional space. For each $0\leq 0\leq i\leq N\text{,}$ let $c_i$ be a $k$–colouring of the $(k+1)$–element set $\{w_0,\ldots,w_k\}$ defined by $c_i(w_j)=c(v_i,w_j)\text{.}$

Since each of the $N+1$ sets $P_i$ can be coloured in $N$ ways, by the Pigeonhole Principle there are $0\leq i_1\lt i_2\leq N$ such that $c_{i_1}=c_{i_2}\text{,}$ i.e., such that $c(v_{i_1},w_j)=c(v_{i_2},w_j)$ for each $0\leq j\leq k\text{.}$ Since $c$ is a $k$–colouring and since the set $\{0,1,\ldots,k\}$ has $k+1$ elements, by the Pigeonhole Principle, there are $0\leq j_1\lt j_2\leq k$ such that $c(v_{i_1},w_{j_1})=c(v_{i_1},w_{j_2})=c(v_{2_1},w_{j_2})=c(v_{i_2},w_{j_1})\text{.}$ Hence, there are four points, $(v_{i_1},w_{j_1})\text{,}$ $(v_{i_1},w_{j_2})\text{,}$ $(v_{i_2},w_{j_1})$ and $(v_{i_2},w_{j_2})\text{,}$ which form a monochromatic rectangle, that is congruent to $R\text{.}$

(b) Let $\mathbf{a}$ and $\mathbf{b}$ be two side vectors of the parallelogram $R\text{.}$ Since $R$ is non–rectangular, $\mathbf{a}\cdot \mathbf{b}\neq 0\text{.}$ Let $\mathbf{a}\cdot\mathbf{b}=1\text{.}$ We claim the Ramsey number $n(4,R)$ does not exist.

Let $n\in \mathbb{N}$

Let $c$ be a $4$–colouring of the $n$–dimensional Euclidean space defined, for $\mathbf{w} \in E^n$ and $i\in\{0,1,2,3\}\text{,}$

\begin{equation*} c(\mathbf{w})=i \Leftrightarrow \lfloor \mathbf{w}\cdot \mathbf{w}\rfloor =\lfloor \mathbf{w}^2\rfloor\equiv i\pmod{4} \end{equation*}

We claim there is no $c$–monochromatic set congruent to $R\text{.}$

Suppose by contradiction that there is such a set $R^\prime\text{,}$ then $R'=\{\mathbf{w},\mathbf{w}+\mathbf{a'},\mathbf{w}+\mathbf{b'},\mathbf{w}+\mathbf{a'}+\mathbf{b'}\}\text{,}$ where $\mathbf{a'},\mathbf{b'}\in E^n\text{.}$ Since this set is monochromatic, it follows that

\begin{equation*} \lfloor \mathbf{w}^2\rfloor\equiv \lfloor(\mathbf{w}+\mathbf{a'})^2\rfloor\equiv \lfloor(\mathbf{w}+\mathbf{b'})^2\rfloor\equiv \lfloor(\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2\rfloor\pmod{4} \end{equation*}

i.e., it follows that

\begin{equation*} \lfloor \mathbf{w}^2\rfloor-\lfloor (\mathbf{w}+\mathbf{a'})^2\rfloor-\lfloor(\mathbf{w}+\mathbf{b'})^2\rfloor+\lfloor(\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2\rfloor\equiv 0\pmod{4}. \end{equation*}

On the other hand, since for some $\theta_1,\theta_2,\theta_3,\theta_4\in[0,1)\text{,}$ $\lfloor \mathbf{w}^2\rfloor=\mathbf{w}^2-\theta_1\text{,}$ $\lfloor (\mathbf{w}+\mathbf{a'})^2\rfloor=(\mathbf{w}+\mathbf{a'})^2-\theta_2\text{,}$ $\lfloor (\mathbf{w}+\mathbf{b'})^2\rfloor=(\mathbf{w}+\mathbf{b'})^2\theta_3\text{,}$ and $\lfloor(\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2\rfloor=\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2-\theta_4\text{,}$ it follows that

\begin{equation*} \lfloor \mathbf{w}^2\rfloor-\lfloor (\mathbf{w}+\mathbf{a'})^2\rfloor-\lfloor(\mathbf{w}+\mathbf{b'})^2\rfloor+\lfloor(\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2\rfloor =\\ \mathbf{w}^2- (\mathbf{w}+\mathbf{a'})^2-(\mathbf{w}+\mathbf{b'})^2+\mathbf{w}+\mathbf{a'}+\mathbf{b'})^2+\theta_1-\theta_2-\theta_3+\theta_4=\\ 2\mathbf{a'}\cdot\mathbf{b'}+\Theta,\\ \end{equation*}

where $\Theta=\theta_1-\theta_2-\theta_3+\theta_4\in (-2,2)\text{.}$

Since we assume $\mathbf{a}\cdot\mathbf{b}=1\text{,}$ $2\mathbf{a'}\cdot\mathbf{b'}+\Theta=2+\Theta\in(-4,4)$ is not divisible by 4.

Thus, there is no $c$–monochromatic set that is congruent to $R\text{.}$
